Starter for Forklifts - A starter motors today is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid mounted on it. When current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion with the starter ring gear that is seen on the engine flywheel.
The solenoid closes the high-current contacts for the starter motor, which starts to turn. After the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in only one direction. Drive is transmitted in this manner via the pinion to the flywheel ring gear. The pinion continuous to be engaged, like for instance in view of the fact that the operator fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This actually causes the pinion to spin separately of its driveshaft.
The actions mentioned above would prevent the engine from driving the starter. This vital step stops the starter from spinning really fast that it can fly apart. Unless adjustments were made, the sprag clutch arrangement would preclude making use of the starter as a generator if it was used in the hybrid scheme mentioned earlier. Usually a standard starter motor is intended for intermittent use that will stop it being utilized as a generator.
Hence, the electrical components are meant to be able to function for more or less less than thirty seconds to avoid overheating. The overheating results from too slow dissipation of heat because of ohmic losses. The electrical parts are designed to save weight and cost. This is truly the reason the majority of owner's guidebooks utilized for vehicles suggest the driver to stop for at least ten seconds after each 10 or 15 seconds of cranking the engine, if trying to start an engine which does not turn over at once.
The overrunning-clutch pinion was introduced onto the marked during the early 1960's. Prior to the 1960's, a Bendix drive was used. This particular drive system works on a helically cut driveshaft which has a starter drive pinion placed on it. Once the starter motor begins turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to exceed the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
During the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design that was developed and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights inside the body of the drive unit. This was an enhancement in view of the fact that the typical Bendix drive utilized in order to disengage from the ring as soon as the engine fired, even if it did not stay running.
When the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for example it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement can be prevented before a successful engine start.
